Product Details

Key Specification

• Honeycomb Briquette effect
  It simulates and adopts the burning principle of honeycomb briquette; it is easy to transform the original block of radiator to various modules, as well as to enable air to convect and fully pass through the gaps between modules by utilizing the honeycomb effect, thus to remove the heat rapidly, and reduce temperature by around 20 ℃.
• Heat dissipation of the whole structure
  It is available to make clever use of module bracket that only play a supporting role, and to transform it to a “thermal bracket” that is capable of conducting the module’s heat to the light shell as a structural part, thus to promote the cooling effect of radiator of cooling module, the design aims to fully utilize the surface area of structural parts to transfer heat to air.
• Double-coupling IP68 protection
  It adopts the screw-free structure to avoid the penetration of water vapor through the screw hole; its double silicon-rubber rings insulate LEDs  with the outside environment completely, thus to eliminate any erosion to chips and PCB boards from outside.
• “Ultra Robust” module technology
  Each LED is equipped with bypass protection, to protect single-circuit structure of the full connection series, even open or short circuit fault can’t affect current and voltage distribution of other LED, the other LED can work under the normal operating mode, thus extending the life cycle of the whole module.
• Independent multi-circuit constant-current output Each circuit is independently controlled; any failure in single circuit does not affect the normal work of other circuits. If a single LED unit is damaged, the current distribution isalso even in the entire series and parallel structure, thus protect the whole system and make sure the life span as long as possible.
• PHILIPS LUXEON Rebel, PHILIPS LUXEON Rebel ES
• Input: AC90-305V
• Color Temperature: 4000K, 6000K
• IP protection:IP68
• Surge Votage protecion: 6KV
• Based on modules, we have different wattages: 80W/120W/160W/200W/240W/280W
